Amorair HVAC bag filter(pocket filter) features a high dust holding capacity and is suitable for pre-filtering in high airflow scenarios. It is widely used in air filtration systems for commercial, industrial, and residential applications, making it a cost-effective choice for air filtration. FEATURES： - High dust-holding power & long service life - Economy version filter with high quality - Low initial resistance to save energy - Available for custom sizes for different needs.
Amorair bag filters represent a fundamental and highly efficient class of air filtration technology widely deployed in commercial, industrial, and HVAC systems. They are composed of multiple bag-shaped filter media and metal frames and can filter larger particles from the air. Bag filters have a simple structure and significantly reduce energy costs due to their extremely low initial resistance and high dust-holding capacity.
Applications :
• Pre-filtration for air conditioning and ventilation systems to prevent dust accumulation and contamination within the system
• Pre-filtration for large air compressors
• Central ventilation and air conditioning systems, as well as return air filtration for cleanrooms
Frame Material Galvanized Steel / Aluminum
Media Synthetic Fiber
U.S. Efficiency MERV6,MERV8,MERV10,MERV11,MERV13,MERV14,MERV15
Euro Efficiency G3,G4,M5,M6,F7,F8,F9,
Max Temperature 60 °C (140 °F)
Connection Angle Aluminum Alloy/ High Temperature Resistant Plastic
Bag Quantity 3PCS-12PCS
Frame Thickness 20mm (0.79″) / 21mm (0.83″) / 26mm (1″) / 47mm (1.85″), custom upon request
